Placa de Baza GIGABYTE X870 AORUS ELITE WIFI7 ICE AM5
1.527,00 RON
(TVA inclus)
Costurile de livrare nu sunt incluse
Cum te putem ajuta?
Descriere
Placa de Baza GIGABYTE X870 AORUS ELITE WIFI7 ICE AM5 4x DDR5, 1x PCIE Gen5 x16 2x PCIE 4.0 x4, 4x M.2, 4x SATA 6GB/s, ATX
Detalii
SKU
X870 A ELITE WF7 ICE
EAN
4719331864682
Categorii
Brand
PCI
0
Serial-or-Paralel
No/No
USB3
4-8
PCI-Ex1
0
PCI-Ex16
3
Wi-Fi
Yes
Onboard-CPU
No
Component for
PC
On-board graphics card
Yes
Weight
2.4 kg
Memory channels
Dual-channel
Ethernet LAN
Yes
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
Bluetooth version
5.4
HDMI ports quantity
1
HDMI version
2.1
USB4 Gen 3x2 ports quantity
2
On-board graphics card model
AMD Radeon Graphics
Processor manufacturer
AMD
Country of origin
China
Product colour
White
PCI Express x16 (Gen 5.x) slots
1
DisplayPort version
1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
Headphone outputs
1
USB 3.2 Gen 2x2 Type-C ports quantity
0
USB4 Gen 2x2 ports quantity
0
DisplayPorts quantity
0
PCI Express x16 (Gen 4.x) slots
1
USB 2.0 ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
Battery weight
3 g
Lithium weight per battery
0.07 g
Number of battery cells
1
Battery technology
Lithium-Manganese Dioxide (LiMnO2)
Battery type
CR2032
Clear CMOS button
Yes
ACPI version
5.0
Desktop Management Interface (DMI) version
2.7
System Management BIOS (SMBIOS) version
2.7
BIOS type
UEFI AMI
BIOS memory size
256 Mbit
Clear CMOS jumper
Yes
1st M.2 largest key size
25110
1st M.2 highest PCI Express generation
5.0
2nd M.2 largest key size
22110
3rd M.2 largest key size
22110
Motherboard form factor
ATX
Motherboard chipset family
AMD
Audio output channels
7.1 channels
HDCP
Yes
Parallel processing technology support
Not supported
DirectX version
12.0
Maximum resolution
4096 x 2160 pixels
Front panel connector
Yes
Number of CPU fan connectors
2
TPM connector
Yes
RGB LED pin header
Yes
Number of RGB LED pin headers
4
12V power connector
Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
Number of SATA III connectors
4
Front panel audio connector
Yes
ATX Power connector (24-pin)
Yes
CPU fan connector
Yes
EPS power connector (8-pin)
Yes
Number of memory slots
4
Memory slots type
DIMM
Unbuffered memory
Yes
Supported memory types
DDR5-SDRAM
Maximum internal memory
256 GB
Maximum internal memory per slot
64 GB
ECC сompatibility
Non-ECC
Bundled software
Norton Internet Security (OEM version)
LAN bandwidth management software
Antenna included
Yes
Screws included
Yes
Package width
335 mm
Package depth
270 mm
Package height
80 mm
DVI-D ports quantity
0
Processor socket
Socket AM5
Supported processor sockets
Socket AM5
Compatible processor series
AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
WiFi-AP antenna jack
2
Microphone in
Yes
VGA (D-Sub) ports quantity
0
Supported storage drive types
HDD & SSD
Number of HDDs supported
4
RAID support
Yes
RAID levels
0, 1, 10
Width
305 mm
Depth
244 mm
Height
35 mm
MB-Format
ATX
RAM-Slots
4
MB-Socket
AM5
USB 2.0 connectors
2
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
Ethernet interface type
2.5 Gigabit Ethernet
Number of SATA II connectors
0
Number of SATA connectors
0
Windows operating systems supported
Windows 11 x64
Total number of SATA connectors
4
Supported memory clock speed (max)
8200 MHz
Maximum internal memory supported by processor
256 GB
PCI Express x16 (Gen 3.x) slots
1
Motherboard chipset
AMD X870
USB 3.2 Gen 2x2 connectors
1
S/PDIF out port
Yes
Number of M.2 (M) slots
4
Number of storage drives supported
8
Discrete graphics support
Yes
LAN controller
Realtek RTL8125
PCI Express x8 (Gen 3.x) slots
0
Number of chassis fan connectors
6
PS/2 ports quantity
0
WLAN controller model
MediaTek MT7925
PCI Express x1 (Gen 3.x) slots
0
PCI Express x1 (Gen 4.x) slots
0
PCI Express x4 (Gen 4.x) slots
0
4th M.2 highest PCI Express generation
4.0
PCI Express x8 (Gen 4.x) slots
0
PCI Express x8 (Gen 5.x) slots
0
2nd M.2 highest PCI Express generation
5.0
3rd M.2 highest PCI Express generation
5.0
4th M.2 largest key size
22110
Audio Chip
Realtek ALC1220
Number of EPS power connectors (8-pin)
2
Supported memory clock speeds
4400,4800,5200,5600,6000,6200,6400,6600,6666,6800,7000,7200,7600,7800,8000,8200 MHz
PCI Express x4 (Gen 3.x) slots
0
Package weight
2.74 kg
Number of water pump connectors
3
PC health monitoring
Fan, Noise, Temperature, Voltage, Water cooling
Number of displays supported
4
Supported storage drive interfaces
M.2
