Card reader integrated
Yes
Mobile network connection
No
AC adapter input voltage
100 - 240 V
Front camera HD type
Full HD
Top Wi-Fi standard
Wi-Fi 6E (802.11ax)
AC adapter frequency
50/60 Hz
Wi-Fi standards
Wi-Fi 6E (802.11ax)
Front camera resolution
1920 x 1080 pixels
Combo headphone/mic port
Yes
Total storage capacity
512 GB
Total SSDs capacity
512 GB
Number of SSDs installed
1
On-board graphics card
Yes
Discrete graphics card
No
Discrete graphics card model
Not available
USB Type-C DisplayPort Alternate Mode
Yes
Number of built-in speakers
2
Privacy type
Privacy shutter
Display diagonal
40.6 cm (16)
Display resolution
1920 x 1200 pixels
On-board GPU manufacturer
Intel
Spill-resistant keyboard
Yes
Memory clock speed
5600 MHz
Memory channels
Dual-channel
Internal memory type
DDR5-SDRAM
Memory form factor
SO-DIMM
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
Ethernet LAN (RJ-45) ports
1
Efficient-core base frequency
1.5 GHz
Processor manufacturer
Intel
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
SSD interface
PCI Express 4.0
Native aspect ratio
16:10
Standard Ports
1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
Storage Slot
Two M.2 2280 PCIe 4.0 x4 slots
Keyboard
Backlit, English (EU)
Mil-Spec Test
MIL-STD-810H military test passed
System Management
Non-vPro
Ethernet
100/1000M (RJ-45)
Speakers
Stereo speakers, 2W x2, Dolby Audio™
Power Adapter
65W USB-C (3-pin)
Memory
1x 16GB SO-DIMM DDR5-5600
Max Memory
Up to 64GB DDR5-5600
Chipset
Intel SoC Platform
WLAN + Bluetooth
Wi-Fi 6E, 802.11ax 2x2 + BT5.3
Other Security
Camera privacy shutter
Storage
512GB SSD M.2 2242 PCIe 4.0x4 NVMe
Touchpad
Buttonless Mylar surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
Card Reader
SD Card Reader
Security Chip
Firmware TPM 2.0 Enabled
Base Warranty
1-year, Courier or Carry-in
Maximum refresh rate
60 Hz
Contrast ratio (typical)
1000:1
Battery technology
Lithium-Ion (Li-Ion)
Memory layout (slots x size)
1 x 16 GB
Compliance certificates
RoHS
Other Certifications
TÜV Rheinland Low Blue Light (Software Solution)
Operating temperature (T-T)
5 - 35 C
Camera
FHD 1080p + IR Hybrid with Privacy Shutter
Display
16 WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC, 60Hz
Green Certifications
ErP Lot 6/26
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
Performance-core base frequency
2 GHz
Display brightness
300 cd/m
Neural processor unit (NPU)
Intel AI Boost
Windows Studio effects support
Yes
AI software frameworks supported by NPU
DirectML, ONNX RT, OpenVINO, Windows ML
USB Power Delivery (USB PD)
Yes
Processor family
Intel Core Ultra 7
Low Power Efficient-cores
2
Low Power Efficient-core Base Frequency
700 MHz
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
Maximum internal memory
64 GB
Fast charging time (50%)
30 min
Processor boost frequency
5.1 GHz
On-board graphics card family
Intel Arc Graphics
Low Power Efficient-core Max Turbo Frequency
2.5 GHz
Processor base power
28 W
Maximum turbo power
115 W
USB Type-C charging port
Yes
Cable lock slot type
Kensington
Operating system installed
No
Storage relative humidity (H-H)
5 - 95%
Compatible memory cards
SD
Thunderbolt 4 ports quantity
1
Keyboard language
English
Special Features
Modern Standby
M.2 SSD size
2242 (22 x 42 mm)
Efficient-core Max Turbo Frequency
4.4 GHz
Performance-core Max Turbo Frequency
5.1 GHz
Case Material
Aluminium (Top), PC-ABS (Bottom)
NPU
Integrated Intel AI Boost, up to 13 TOPS
Motherboard chipset
Intel SoC
Surface Treatment
Anodizing Sandblasting (Top), Texture (Bottom)
Dimensions (WxDxH)
356 x 253.5 x 17.5 mm (14.01 x 9.98 x 0.69 inches)
Processor generation
Intel Core Ultra (Series 2)
Processor
Intel Core™ Ultra 7 255H, 16C (6P + 8E + 2LPE) / 16T, Max Turbo up to 5.1GHz, 24MB
Audio Chip
Realtek ALC3287
Storage temperature (T-T)
5 - 43 C
Operating relative humidity (H-H)
8 - 95%
Maximum shipping altitude
3048 m
NPU performance up to
13 TOPs
USB Sleep-and-Charge ports
1
On-board graphics card model
Intel Arc 140T
Total processor performance up to
96 TOPs
GPU performance up to
74 TOPs
Housing material
Acrylonitrile butadiene styrene (ABS), Aluminium, Polycarbonate (PC)
Ethernet LAN data rates
1000,100 Mbit/s
Sustainability certificates
ENERGY STAR, EPEAT Gold, ErP, TCO
Graphics
Integrated Intel Arc™ 140T GPU Functions as Intel Graphics
Max Storage Support
Up to two drives, 2x M.2 SSD
• M.2 2280 SSD up to 2TB each
Password protection type
HDD, Power on, Supervisor, User
Continuous video playback time
13.1 h
Certification
TÜV Rheinland Low Blue Light (Software Solution)
MIL-STD-810H military test passed
Physical Locks
Kensington Nano Security Slot, 2.5 x 6 mm
