Card reader integrated
Yes
Housing material
Aluminium
Memory form factor
On-board
Mobile network connection
No
AC adapter input voltage
100 - 240 V
AC adapter frequency
50/60 Hz
High Dynamic Range (HDR) supported
Yes
Total storage capacity
1 TB
Maximum refresh rate
120 Hz
Contrast ratio (typical)
1000000:1
Number of built-in speakers
6
Combo headphone/mic port
Yes
Number of SSDs installed
1
On-board graphics card
Yes
USB Type-C DisplayPort Alternate Mode
Yes
Privacy type
Privacy shutter
Front camera resolution (numeric)
5 MP
Display diagonal
40.6 cm (16)
On-board GPU manufacturer
Intel
Discrete graphics card
Yes
Discrete GPU manufacturer
NVIDIA
Memory channels
Dual-channel
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
Wi-Fi standards
Wi-Fi 7 (802.11be)
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
Thunderbolt 4 ports quantity
2
Efficient-core base frequency
1.5 GHz
Processor manufacturer
Intel
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
SSD interface
PCI Express 4.0
Native aspect ratio
16:10
Ethernet
No Onboard Ethernet
Color Calibration
Factory Color Calibration
Power Adapter
170W Slim Tip (3-pin)
Standard Ports
1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
Chipset
Intel SoC Platform
Security Chip
Firmware TPM 2.0
Bundled software
Office Trial
Keyboard
Backlit, English
Surface Treatment
Aluminium Stamping (Anodized with Sandblasting)
Case Material
Aluminium (Top), Aluminium (Bottom)
Memory slots
Memory soldered to systemboard, no slots, dual-channel
Max Memory
32GB soldered memory, not upgradable
Storage
1TB SSD M.2 2242 PCIe 4.0x4 NVMe
Base Warranty
2-year, Courier or Carry-in
Storage Slot
Two M.2 slots
• One M.2 2242 PCIe 4.0 x4 slot
• One M.2 2280 PCIe 4.0 x4 slot
Card Reader
SD Card Reader
Operating System
Windows 11 Home, Romanian / English
Internal memory type
LPDDR5x-SDRAM
Maximum internal memory
32 GB
Operating system architecture
64-bit
Battery technology
Lithium-Ion (Li-Ion)
Compliance certificates
RoHS
Operating temperature (T-T)
5 - 35 C
Other Certifications
Intel Evo™ Platform
Green Certifications
Carbon Neutral Certified
Dimensions (WxDxH)
362.72 x 253.69 x 17.9 mm (14.28 x 9.99 x 0.70 inches)
Camera
5.0MP + IR with E-shutter
Touchpad
Buttonless glass surface multi-touch touchpad, supports Precision TouchPad (PTP), 95 x 150 mm (3.75 x 5.91 inches)
WLAN + Bluetooth
Wi-Fi 7, 802.11be 2x2 + BT5.4
Bundled Accessories
Lenovo USB-C 4-in-1 Hub Gen 2
Discrete graphics card memory
8 GB
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
Performance-core base frequency
2 GHz
Neural processor unit (NPU)
Intel AI Boost
Windows Studio effects support
Yes
AI software frameworks supported by NPU
DirectML, ONNX RT, OpenVINO, Windows ML
USB Power Delivery (USB PD)
Yes
Processor family
Intel Core Ultra 7
Low Power Efficient-cores
2
Low Power Efficient-core Base Frequency
700 MHz
Processor boost frequency
5.1 GHz
On-board graphics card family
Intel Arc Graphics
Low Power Efficient-core Max Turbo Frequency
2.5 GHz
Processor base power
28 W
Maximum turbo power
115 W
USB Type-C charging port
Yes
Display resolution
2880 x 1800 pixels
Storage relative humidity (H-H)
5 - 95%
Compatible memory cards
SD
Keyboard language
English
M.2 SSD size
2242 (22 x 42 mm)
Efficient-core Max Turbo Frequency
4.4 GHz
Performance-core Max Turbo Frequency
5.1 GHz
Storage Support
Up to two drives, 2x M.2 SSD
• M.2 2242 SSD up to 1TB each
NPU
Integrated Intel AI Boost, up to 13 TOPS
Motherboard chipset
Intel SoC
Processor generation
Intel Core Ultra (Series 2)
Operating system installed
Windows 11 Home
Processor
Intel Core™ Ultra 7 255H, 16C (6P + 8E + 2LPE) / 16T, Max Turbo up to 5.1GHz, 24MB
Storage temperature (T-T)
5 - 43 C
Operating relative humidity (H-H)
8 - 95%
Maximum shipping altitude
3048 m
Memory
32GB Soldered LPDDR5x-8400
Speakers
6 stereo speakers, 2W x4 (dual side woofers), 2W x2 (tweeters), optimized with Dolby Atmos, Smart Amplifier (AMP)
Graphics
NVIDIA GeForce RTX™ 5060 8GB GDDR7
Display
16 2.8K WQXGA+ (2880x1800) OLED 1100nits (peak) / 500nits (typical) Glossy, 100% DCI-P3, 100% sRGB, 120Hz, Eyesafe, Dolby Vision, TÜV Low Blue Light, DisplayHDR™ True Black 1000, X-Rite, PureSight Pro
NPU performance up to
13 TOPs
Continuous video playback time
14 h
Sustainability certificates
ENERGY STAR, EPEAT Gold
Discrete graphics memory type
GDDR7
Discrete graphics card model
NVIDIA GeForce RTX 5060
USB Sleep-and-Charge ports
1
Operating system language
English, ROM
On-board graphics card model
Intel Arc 140T
Total processor performance up to
96 TOPs
GPU performance up to
74 TOPs
Audio Chip
Realtek ALC3306
High Dynamic Range (HDR) technology
DisplayHDR True Black 1000, Dolby Vision
USB Type-C required charging power (min)
65 W
USB Type-C required charging power (max)
100 W
Display brightness
1100 cd/m
Standard Dynamic Range (SDR) brightness
500 cd/m
Maximum display brightness (HDR)
1100 cd/m
Memory clock speed
8400 MHz
Password protection type
BIOS, HDD
Box contents
Lenovo USB-C 4-in-1 Hub Gen 2
